MAIN FEATURES
◆Pure sine wave output for compatibility with loads of different types
◆Visualization of operation status of the equipment through a digital LCD
◆A wide range of input voltage, accurate output and automatic voltage stabilization
◆Settable battery type and charge current for the charge management of batteries of different types of FT/FT-B
◆Settable mains supply preferred mode, energy-saving mode and battery preferred mode for easy meeting of the needs of different users
◆Overall protection functions (battery over voltage protection, battery under voltage protection, overload protection, short circuit protection and over temperature protection)
| Product Specifications | |||||||
| Model: FT Pro | 3KW | 4KW | 5KW | 6KW | |||
| Rated Power | 3000W | 4000W | 5000W | 6000W | |||
| Battery | Rated Voltage | 12VDC/24VDC/48VDC | 24VDC/48VDC | 48VDC/96VDC | |||
| Charge Current | 30A (default) -C0-C6 | ||||||
| Battery Type | U0-U7 | ||||||
| Input | Voltage Range | 85-138VAC/170-275VAC | |||||
| Frequency | 45-65Hz | ||||||
| Product Size:L"W"H(mm) | 486*247*179 | 555*307*189 | |||||
| Package Size: L"W"H(mm) | 550*310*230 | 640*370*240 | |||||
| Output | Voltage Range | 110VAC/220VAC; ±5%( Inversion mode) | |||||
| Frequency | 50/60Hz±l%( Inversion mode) | ||||||
| Output Wave | Pure Sine Wave | ||||||
| Conversion Time | <10ms(Typical load) | ||||||
| Efficiency | >85% (80% resistive load) | ||||||
| Overload | 110-120%/30S; >160%/300ms; | ||||||
| Protection Function | Battery overvoltage protection, battery undervoltage protection, overload,protection, short circuit protection, overtemperature protection, etc. | ||||||
| Operation Of Ambient Temperature | 0-40°C | ||||||
| Ambient Temperature For Storage | -15-+50°C | ||||||
| Operation/Storage Ambient | 0-90% No Condensation | ||||||
