What is MPPT and how it works?

MPPT Solar Controller Overview:

• MPPT controller is an advanced,efficient and versatile photovoltaic product.

• The MPPT charge controller is a DC-DC converter that maximizes the efficiency of solar energy systems. It does this by optimizing the voltage match between the solar panel array and the battery.

MPPT Solar Controller Working Principle:

• The MPPT solar controller can detect the power generation voltage of the solar panel, and is used in the solar photovoltaic system to coordinate the work of the solar panel and the battery load.

• By adjusting the working state of the electrical module, the MPPT controller enables the photovoltaic panel to output more electrical energy. It can effectively store the direct current generated by the solar panel in the battery, and track the highest voltage and current value, so that the system can use the maximum power. The output charges the battery.




Working Diagram of MPPT Solar Controller:

Solar Controller Features：

-Intelligent maximum power tracking technology,up to 97% convert efficiency.；

-High precision and high effciency with DSP chip control；

-The PV wide range voltage input, three s tage charging technology；

-The photovoltaic/battery connection reverse protection short-circuit protection /over current protection；

-Display technology parameter with 7 inch touch screen；

-Rs485 remote communication and data transmission (optional).

Advantage:

-The MPPT charge controller manages to optimize the output power of the solar array and minimize energy loss while protecting the battery.

-The controller adopts intelligent battery charging management and has temperature compensation function to effectively manage the battery and extend the battery life.
