English
MAIN FEATURES
◆Pure sine wave output for compatibility with loads of different types
◆Visualization of operation status of the equipment through a digital LCD
◆A wide range of input voltage, accurate output and automatic voltage stabilization
◆Settable battery type and charge current for the charge management of batteries of different types of FT/FT-B
◆Settable mains supply preferred mode, energy-saving mode and battery preferred mode for easy meeting of the needs of different users
◆Overall protection functions (battery over voltage protection, battery under voltage protection, overload protection, short circuit protection and over temperature protection)
| Product Specifications | ||||||
| Model:FT-B | 0.3KW | 0.5KW | 0.7KW | 0.7KW | 1KW | |
| Rated Power | 300W | 500W | 700W | 700W | 1000W | |
| Battery | Rated Voltage | 12VDC/24VDC | 24VDC | 12VDC | 12VDC/24VDC | |
| Input | Voltage Range | 73-138VAC/145-275VAC | ||||
| Frequency | 45-65Hz | |||||
| Product Size:L"W"H(mm) | 302*122*188 | 316*149*215 | ||||
| Package Size: L"W"H(mm) | 375*195*260 | 410*215*280 | ||||
| Output | Voltage Range | 110VAC/220VAC; ±5%( Inversion mode) | ||||
| Frequency | 50/60Hz±1%( Inversion mode) | |||||
| Output Wave | Pure Sine Wave | |||||
| Conversion Time | < 10ms(Typical load) | |||||
| Efficiency | >85% (80% resistive load) | |||||
| Overload | 110-120%/30S; >160%/300ms; | |||||
| Protection Function | Battery overvoltage protection, battery undervoltage protection, overload,protection, short circuit protection, overtemperature protection, etc. | |||||
| Operation Of Ambient Temperature | 0-40°C | |||||
| Ambient Temperature For Storage | -15-+50°C | |||||
| Operation/Storage Ambient | 0-90% No Condensation | |||||
